The state-of-the-art regulators
of the MAX Series have been
designed to offer simple and
efficient regulation features.
The whole range of computer
regulators is based on
CIRCUTOR's FCP system
(Fast Computerized Program),
offering a set of unique
performance features. Its
main features are as follows:
Shows by display: cos
φ
,
voltage, current, THD(I) and,
besides, records in memory
maximum values for voltage
and current provides the
“phase selection” function,
that allows the user choosing
the power line phase where
the measuring current
transformer (C.T.) has been
placed in allows viewing in
display the variation of cos
φ
,
line current and THD(I), when
manually connecting or
disconnecting capacitor
steps.
Indication by display or
through relay output of
following alarm conditions:
Compensation failure,
Over-compensation,
Over-voltage, Over-current,
C.T. not connected or open,
Line current below measur-
able value.
• Panel mounted electrical
system analyzer (96 x 96
mm) which measures,
calculates and displays the
main electrical parameters in
balanced and unbalanced
three-phase systems
• Slim line analyzer (only 50
mm deep)
• Power demand meter
function (A / A III / kW III /
kV•A III)
• Current reading using
external transformers .../5A
(insulated inputs, according
to type)
• Option for measuring in Low
and Medium Voltage systems
• RS-485 communication
(MODBUS RTU)
• Compatible with the Power
Studio / Scada system
• 4 line backlit LED display
• Allows selection of default
page
• Universal power supply
available in "Plus" typeand
Medium Voltage systems
• RS-485 communication
(MODBUS RTU)
• Compatible with the Power
Studio / Scada system
• 4 line backlit LED display
• Allows selection of default
page
• Universal power supply
available in "Plus" type
Power Factor Regulator Computer MAX Series
P19
CVM-NRG 96 System Analyzer
P18
CVM-NRG 96 System Analyzer
Power Factor Regulator
PRODUCT CATALOGUE
10
