Electrical features
Auxiliary power supply
230 V a.c. (± 20%) 50 … 60 Hz
Output contacts
250 V a.c. 6 A
Operating temperature
-10 ºC / +50 ºC
Mechanical features
Mounting
DIN rail
Dimensions
2 modules
Weight
163 g
Protection grade Terminals IP 20, Front side: IP 41
Standards
IEC 61008-1, IEC 755, IEC 255-5
Display Mechanism IDn (A) Delay (s) Type Code
LED
electronic
0,03...5 0,02...5
RN-R P12132
Current Measuring Tranformers
are specifically designed for
their use in those places with a
limited free space for their
installation such as close to
circut-breakers and any position
with a minimum seperation
space between the bus bars.
Features
• Easy Installation procedure
• Ideal for circut breaker output
side
• High accuracy
Weight
Useful diameter ø(mm)
Type
Code
148 g
35 ø
WN-35
P10211
281 g
70 ø
WN-70
P10212
433 g
105 ø
WN-105
P10213
574 g
140 ø
WN-140
P10214
1.201g
210 ø
WN-210
P10215
Earth Leakage Relay - RN Series
P21
Differential Transformer WN series
P22
Current Measuring Transformers
P20
Current Measuring Transformers
Earth Leakage Relay
Differential Transformer
11
