HLMK Series Current Transformer
P8
HLAY5 Selector Switch, Emergency stop & Push Button
P9
Technical Data
Standard: IEC 60044-1
Primary current: 100A-5000A
Secondary approval: 5A, 1A
Maximum voltage: 0.66kV
Class: 0.5, 1.0, 3.0
Short time thermal current: Ith=100Ih
Rated security coefficient: FS<5
HLMK Series Current Transformer
HLAY5 series of pushbutton switches provide: Control and indicate the status of the circuit
HLD11 Indicator Light
P7
HLAY5 Selector Switches
HLAY5 Emergency Stop
HLAY5 Pushbutton Switches
HLD 11 Series of indicator light provide:
Pilot signal, anticipating signals
Emergency signals and other instructions incidents signal use
Technical Data
HLD11 Indicator Light
Rated Voltage(V)
Rated Current(MA)
Working Life (H)
AC/DC
<50
30000
Brightness of the light(cd/m2)
240
Power Frequency withstand voltage
Before board protect degree
2500 V AC 1min
IP65
<20
AC
PROLIANCE SWITCHGEAR SOLUTIONS L L C
PRODUCT CATALOGUE
06
