HKG816 Series Digital Times Switch
P11
HRT Fuse Puller, 10x38 Fuse Carrier & 10x38 fuse links
P12
HRT18 Fuse
HRT18 fuse provide:
Protection of circuits against
overload current, Protection of
circuits against short-circuit
current
Rated working current 2-63A
Rated operation voltage 380V
Rated breaking capacity 100KA
H72 & 96 Series Panel Meter
P10
HRT16 Fuse Puller
HRT18 Fuse Carrier
HKG 816 Series Digital Switch
Rated AC frequency of 50 Hz, rated AC control voltage 230V or below
Be used as time control components in automatic control circuit,
according to the scheduled time to time -on or off the circuits.
Non-transparent cover
16-on16-off
AC230V HKG816B230
Transparent cover
8-on- 8-off
AC230V HKG816A230
Material - ABS(frame resistance)
Usage - Assemble and replace HRT16 fuse
Cover
Output loops
Rated control voltage
H72 & 96 Series Panel Meter (Ammeter, Voltmeter, Frequency Meter, P.F Meter)
Standard
IEC 60051
Dielectric strength test
Frequency 50/60Hz
Voltage 2000V, Duration 1 m
Impact test
Max acceleration 147m/s2
Response time
<4s
Angular Deflection
90
Temp.
-25 -+40
Humidity
(25%-80%)RH
Evvironment
No mildew, insects, salt mist, dew in the air,
few sands and dusts are permitted.
Installation
Shall be installed vertically
07
