Switch Disconnector (R/M Isolator) - HDB6IS
P5
HJX2-4P AC Contactor
P6
Residual Current Protection Module
Standard:IEC 61008-1
RCCB Type: AC, A
Sensitivity: 30, 100, 300mA
Switch Disconnector
Standard: IEC 60947-3
HDB6IS switch disconnectors combine the following Function:
• Making and breaking normal load circuits
• Isolation
Number of poles 2,3,4
Rating: 20-125(A)
Residual Current Protection Module (RCCB) - HDB6VR
P4
Standard: IEC 60947-4-1
AC Contactor
Product Name Rated Current Main Current
Coil Voltage Coil Frequency
HJX2
09
04
.
7
09:9A
04:4NO+0NC B:24V
12:12A
95:95A
...
X;440V
08:2NO+2NC
7:50/60Hz
...
05
PRODUCT CATALOGUE
HDB6VR Residual current operated circuit breakers combine the
following functions:
• Protection for users against indirect contacts
• Additional protection for users against direct contacts (30mA)
• Protection for electrical installations against insulation faults (fire
hazard, etc)
PROLIANCE SWITCHGEAR SOLUTIONS L L C
