Molded Case Circuit Breaker (MCCB) - HDM6s
P2
Miniature Circuit Breaker (MCB) - HDB6
P3
Miniature Circuit Breaker
Standard: IEC 60898-1
Trip Curve: B, C and D curves
Breaking Capacity: 3000/4500/6000A
Air Circuit Breaker
Main Characteristics
Frame(A):1600N, 4000H1, 4000H2, 6300L In (A):630 ~ 6300
• Ue (V):400/415, 690
• Poles: 3P & 4P
• Type: Fixed type & Draw-out type
• Certificates: CE, KEMA
• Standards:IEC 60947-2
HDM6s Molded Case Circuit Breaker
Standard: IEC 60947-2
Basic Technical Data
• Rated Insulation Voltage Ui: AC 800V (Frame 63AF: AC 690V)
• Rated Impulse Withstand Voltage Uimp: 8KV (Frame 63AF: 6KV)
• Rated Working Voltage Ue: AC 415V (Frame 63AF: AC 400)
• Rated Working Frequency: 50Hz/60Hz
• Utilization Category: A
• Isolation Function: Applicable for all series
Air Circuit Breaker(ACB) - HDW9
P1
PRODUCT CATALOGUE
04
PROLIANCE SWITCHGEAR SOLUTIONS L L C
